6-50 CASE Revision C
2060290-201
After the Test — Post Test Review
Enabling the Zoom Mode
1. Click the zoom icon.
2. Position the magnifying glass on the region of interest and click.
An enlarged view of the selected region appears.
The operating controls basically remain the same. When you click the
printer icon, however, only that page will be printed.
A Click icon to print the displayed screen.
B Click icon to initiate one of the following actions
the ECG strip is saved
the ECG strip is printed, or
the ECG strip is saved and printed (see section “Writer Tab” on page 12-12).
To Next Page
