6-38 CASE Revision C
2060290-201
After the Test — Post Test Review
Viewing TWA Medians, Replacing max. TWA Values
1. Locate the TWA value in the trend graph of interest and click.
2. A new window with the corresponding median complexes will open.
3. Click on the TWA value in the median complex window: a new
window with the new and old TWA values appears.
4. Click Yes and the TWA value will be changed.
Note
Dashed lines appear in case of noisy signal and/or when the heart
rate is too high (see TWA Heart Rate Limit in Chapter 12, “System
Settings” under “TWA Tab” on page 12-30).
