4-4 CASE Revision C
2060290-201
Selecting a Patient Record from the Local Database
Selecting a Patient Record
1. Enter the patient's last name or the patient ID to find a particular
patient. It is sufficient to enter the first letters or numbers.
2. Select the test type.
3. Check the patient information. If it needs to be modified:
a. Type over the current data and
b. click Accept.
4. Follow these steps to start a test with the selected patient:
a. Click New Test or
b. press Enter.
5. As an alternative you can select a patient by double-clicking the
name.
6. If you are working with the keyboard only:
a. Select the test type with the cursor keys
b. press the Tab key
c. enter the patient's name and
d. confirm the selection with Enter.
Note
Once you have selected your patient, the acquisition screen for the
new test will appear.
