Post Test Review
Zoom Mode
A zoom factor from 2 to 12 can be selected and the selected segment can
be displayed in all leads.
059A-R
A
B
C
D
E F
A Click to select the lead:
With you scroll through the leads,
with you open the list.
B Click icon to terminate the zoom function.
C Click to select the zoom factor.
D Click icon to print the segment.
E Click icon to copy the segment to the Clipboard.
F Cursor position in mV.
