Revision C CASE 5-17
2060290-201
Post Test Review
Reanalysis
Reanalysis allows you to manually change the position of the ST
measurement marks. The reanalysis can only be performed on ECGs
analyzed with the HEART program (see section “Miscellaneous Tab” on
page 12-8).
On the reanalysis screen the medians of all leads are superimposed. The
currently selected lead is highlighted. The measurement marks
determined by the program are shown below the ECG baseline. The
measurement marks above the baseline can be edited. The table in the
top right-hand corner indicates the time intervals.
The T-offset measurement mark can be adjusted in each individual lead
(see page after next).
Measurements can also be performed on the complex.
A Click to select the lead to be highlighted.
B Click to display the medians window.
C Click button to display the tabular summary.
D Click button to perform the reanalysis.
E Click to reset the measurement marks to their original positions.
F Select if you wish to adjust the T-wave offset mark (see next page).
To Next Page
