Revision C CASE 12-19
2060290-201
Exercise Test Setup
Protocol Editor Tab
Click the Protocol Editor tab to open the window.
Selecting the Default Protocol
1. Choose the treadmill B or bicycle ergometer C exercise testing device.
2. Select the default protocol D.
You can either select an existing protocol (e.g. BRUCE) and edit
the parameters, or
You can create a new protocol from a blank template (e.g. TEST
14).
3.
Click
Modify
F to edit existing protocols or create new ones. This
displays the
Protocol Editor
window.
Note
You can select protocols for pharmacological tests (e.g.
Dobutamine) at D.
A Click to print the exercise test setup.
B Click option button to select the treadmill exercise testing device.
C Click option button to select the bicycle ergometer exercise testing device.
D Click down arrow to select a protocol.
E Phase names of the protocol.
F Click to modify or delete protocols (see “Protocol Editor Screen” on page 12-
20).
