Revision C CASE 5-15
2060290-201
Post Test Review
Measuring the ECG
Amplitudes (mV), intervals (ms) and slopes (mV/s) can be measured on
all ECG waveforms.
1. Position the cursor on the first measurement point and click. A
caliper appears.
2. Position the cursor on the second measurement point and click. Now
you will see
the second caliper
the measuring line and
the measurement results
3. Click the right mouse button to remove measurement points.
