8-8 CASE Revision C
2060290-201
Conducting Spirometry Tests
Note
For flow-volume measurements, the patient's cooperation is
essential.
The ambient conditions should be checked every day before
performing spirometry tests; the room temperature is the factor
with the most impact on the test results (see section “Acquisition
Tab” on page 12-35).
Refer to section “Acquisition Tab” on page 12-35 for information
on selecting the Measurement Mode, the Interpretation Mode, or
the Equation for Reference Value Calculation or on entering the
PT Code.
201A-SP
S
R
H
A B
C
E
I
J
K
L
N
M
D
Q
F G
O
P
A Click buttons to change the waveform scale.
B Click option button to display the flow-volume loop.
C Click option button to display the volume-time curve.
D Reference curve.
E Table with actual and reference values.
F Patient data.
G System evaluation area (MILLER square only with LF 501).
H Click to enter test information.
