2-10 CASE Revision C
2060290-201
Function Keypad
Press hold stage to maintain the current stage (automatic stage
sequencing is stopped). Press again to turn off stage hold.
Press new test to prepare the system for a new patient/a new test.
Press comment to enable entry of additional information and values for
the user-defined columns of the tabular summary (see “Configuring the
Tabular Summary” on page 12-14).
Press enter BP to enter the patient's blood pressure.
Press 12 lead to record a 10-second ECG (5 seconds from memory, 5
seconds from when key was pressed).
Press medians to record a medians report.
Press rhythm to record a continuous, real-time ECG rhythm strip
(terminate recording with stop writer).
Press recall to record a one-page rhythm strip of the previous 10 seconds.
Symbol Description
