Revision C CASE 2-13
2060290-201
Preparing the Acquisition Module
Caution
Proper Leadwire Connection — Improper connection will
cause inaccuracies in the ECG.
Trace each individual leadwire from its acquisition
module label to the colored connector and then to the
proper electrode to ensure that it is matched to the
correct label location.
Note
The ECG signal input is isolated and defibrillation-proof only in
conjunction with the CAM-14 acquisition module (type BF).
