GE Concord 4 Series Installation Instructions

Concord 4 Series Systems 8
Table 1 describes the maximum wire length allowed between compatible devices and the panel,
and the minimum and maximum current draw of each device.
Table 1: Maximum Device Wire Length and MIn./Max. Current Draw
Device
Max. Wire Length
to Panel
Standby mA
Draw
Alarm mA Draw
SuperBus 2000 2x16 LCD Alphanumeric Touchpad
22 ga.—300 ft.
18 ga.—750 ft.
15 mA 90 mA
SuperBus 2000 ATP 1000 Alphanumeric Touchpad
22 ga.—300 ft.
18 ga.—750 ft.
12 mA 110 mA
SuperBus 2000 ATP 2100 Alphanumeric Touchpad
22 ga.—300 ft.
18 ga.—750 ft.
30 mA 165 mA
SuperBus 2000 ATP 2600 Alphanumeric Touchpad
22 ga.—300 ft.
18 ga.—750 ft.
30 mA 165 mA
SuperBus 2000 GTS 50
22 ga.—100 ft.
18 ga.—250 ft.
270 mA 300 mA
SuperBus 2000 Fixed Display Touchpad
22 ga.—300 ft.
18 ga.—700 ft.
11 mA 65 mA
SuperBus 2000 RF Transceiver
22 ga.—1,000 ft.
18 ga.—2,500 ft.
45 mA 55 mA
SuperBus 2000 RF Receiver (see note)
22 ga.—1,100 ft.
18 ga.—2,800 ft.
35 mA 35 mA
SuperBus 2000 Phone Interface/Voice Module
22 ga.—40 ft.
18 ga.—120 ft.
25 mA 600 mA
SuperBus 2000 Voice Only Module
22 ga.—40 ft.
18 ga.—120 ft.
20 mA
300 mA (jumper)
600 mA (no jumper)
SuperBus 2000 2 Amp Power Supply no load no load
4 Input/2 Output SnapCard N/A 20 mA 185 mA*
8Z Hardwire Zone Expander SnapCard N/A 38 mA 230 mA*
4 Output SnapCard N/A 1 mA 130 mA*
SuperBus 2000 8Z Input Module
22 ga.—1,800 ft.
18 ga.—4,000 ft.
18 mA 35 mA
SuperBus 2000 4-Relay Output Module
22 ga.—350 ft.
18 ga.—900 ft.
12 mA 180 mA
SuperBus 2000 Energy Saver Module
22 ga.—1,600 ft.
18 ga.—4,000 ft.
20 mA 20 mA
SuperBus 2000 Cellular Backup Module
Standard Power:
22 ga.—15 ft.
18 ga.—40 ft.
90 mA 1600 mA
High Power
22 ga.—10 ft.
18 ga.—30 ft.
90 mA 1900 mA
SuperBus 2000 Automation Module
22 ga.—1,500 ft.
18 ga.—4,000 ft.
30 mA 35 mA
SuperBus 2000 Wireless Gateway-Ready Kit
22 ga.—40 ft.
18 ga.—90 ft.
65 mA 1600 mA
Interrogator 200
22 ga.—3,200 ft.
18 ga.—4,500 ft.
10 mA 10 mA
Interrogator AVM
22 ga.—110 ft.
18 ga.—260 ft.
45 mA 300 mA
2-Wire Smoke Detectors (ESL 429AT, 521B, 521BXT)
22 ga.—330 ft.
18 ga.—330 ft.
70 µA 60 mA
2-Wire Smoke Detectors (System Sensor 2400, 2400TH)
22 ga.—330 ft.
18 ga.—330 ft.
120 µA 80 mA
Hardwire Interior Siren (13-949)
22 ga.—750 ft.
18 ga.—1,500 ft.
0 mA 85 mA
Piezo Dynamic Exterior Siren (13-950)
22 ga.—750 ft.
18 ga.—1,500 ft.
0 mA 150 mA
WWW.DIYALARMFORUM.COM

GE Concord 4 Series Specifications

General

User Codes	230
Backup Battery	12V 4Ah rechargeable battery
Wireless Frequency	319.5 MHz
Communication	POTS, optional cellular and IP modules
Wireless Capability	Yes
Keypad Options	Multiple keypad options including touchscreen
Wired Zones	8 on board
Power Supply	16.5 VAC Transformer
Compatibility	Compatible with GE Security wireless sensors
Zones	Up to 96
Event Buffer	512
