Concord 4 Series Systems
19
Wiring for Status and Alarm Messages
Make the connection shown under “Status and Alarm” in Figure 20 only if the Phone Interface/
Voice Module is being installed in Partition 1 and alarm sounds are desired. In an alarm, the
speaker alternates between alarm siren tones and voice status messages.
Figure 20. Wiring the Phone Interface/Voice Module for Status Only or Status and
Alarm Messages
SuperBus 2000 Energy Saver Module (60-620-01)
Connect the Energy Saver Module to the panel and premises thermostat as shown in Figure 21.
Figure 21. Wiring the Energy Saver Module to the Panel
SuperBus 2000 8Z Input Module (60-774)
Connect the SuperBus 2000 8Z Input Module to the panel as shown in Figure 22.
Connect all necessary input wiring using the Installation Instructions included with the module.
SuperBus 2000 4-Relay Output Module (60-770)
Connect the SuperBus 2000 4-Relay Output Module to the panel as shown in Figure 22.
1
+ 1 2 V
2
A
3
B
4
G N D
5
G N D
6
S P K 1
7
S P K 2
8
A U D 1
9
A U D 2
1 0
G N D
1 1
T I P 1
1 2
T I P 2
1 3
R I N G
2
1 4
R I N G
1
7 8
S P E A K E R
1
+ 1 2 V
2
A
3
B
4
G N D
5
G N D
6
S P K 1
7
S P K 2
8
A U D 1
9
A U D 2
1 0
G N D
1 1
T I P 1
1 2
T I P 2
1 3
R I N G
2
1 4
R I N G
1
Module Terminals
Hardwire Interior
Speaker (60-528)
Not Used
Not Used
Module Terminals
Panel
Terminals
Status Only
Status and Alarm
1
2 3 4 5 6
H E A T
O F F
A / C
5 0 6 0 7 0 8 0 9 0
3 4 5
6
+ 1 2 V
A B U S B
G N D
Panel
Terminals
Thermostat
Energy Saver Module
To HVAC
