Concord 4 Series Systems
83
* These devices not listed, investigated, or verified by UL.
** UL listing applied for.
† Listed, but not tested for compatibility by UL.
†† Total current only for all 2-wire smoke detectors connected to panel 2-wire smoke loop.
Note
When installing SuperBus 2000 RF Receiver Modules, the Antenna Tamper feature must be set to off
(see REPORTING—GLOBAL in the “Programming” section).
Table A2: Hardwire Devices
Part No. Description Qty.
mA
(Max.)
Sub Total
Hardwire Sensors/Detectors
N/A
System Sensor models 2400, or 2400TH or ESL
series 429AT, 521B or 521BXT
80 mA††
13-082* PIR Motion Detector 10 mA
Sirens
13-046 Hardwire Exterior Siren 145 mA
13-949** Hardwire Interior Siren 85 mA
13-950** Piezo Dynamic Exterior Siren 150 mA
SuperBus 2000/Miscellaneous Components
60-746-01 2x16 LCD Alphanumeric Touchpad 90 mA
60-820 Fixed Display LCD Touchpad 65 mA
60-803 2x20 LCD Alphanumeric Touchpad 120 mA
60-804 2x20 VFD Alphanumeric Touchpad 120 mA
60-983 ATP 1000 110 mA
60-984 ATP 2600 165 mA
60-985 ATP 2100 165 mA
600-1013* GTS 50 300 mA
60-836
Voice Only Module (with current jumper installed)
(with current jumper removed)
300 mA
600 mA
60-777-01 Phone Interface/Voice Module 600 mA
600-1025-01-
95R
RF Transceiver 55 mA
60-764-01-95R RF Receiver (see note) 35 mA
600-1019 2 Amp Power Supply N/A
60-756 4 Input/2 Output SnapCard 185 mA
60-757 8Z Hardwire Zone Expander SnapCard 230 mA
60-758 4 Output SnapCard 130 mA
60-774 Hardwire Input Module 35 mA
60-770 Hardwire Output Module 180 mA
60-620-01* Energy Saver Module 20 mA
60-850
60-850-01
Cellular Backup Module (standard power)
Cellular Backup Module (high power)
1600 mA
1900 mA
60-861 Wireless Gateway-Ready Kit 1600 mA
60-677* Interrogator 200 Audio Verification Module 10 mA
60-783-02* Automation Module 35 mA
60-528 Hardwire Interior Speaker 500 mA
13-060 15-Watt Speaker 500 mA
Total power consumption: mA
Total power consumption not to exceed: 1,000 mA
