Concord 4 Series Systems 4
• Phone Test Freq. set to 1
• High Level Rpts set to on
• Low Level Rpts set to on
• Comm. Failure set to on
• RF Tx Timeout set to 4 hours
Central Station Reporting
The panel has been tested with the following central station receivers using SIA and Contact ID
reporting formats:
• CS-5000 Central Station Receiver
• Sur-Gard Central Station Receiver with models SG-DRL2A and SG-CPM2
• Osborne Hoffman Central Station Receiver
Note
The installer must verify the
compatibility between this
panel and the central station
receiver(s) being used.
UL Canada Listed Installations
This section describes the requirements for CUL (UL Canada) Listed installations.
Canadian Standards CSA Certified Accessories
Residential Burglary Alarm System Unit (ULC Subject C1023-1974)
Basic system as described for “UL 1023 Listed Installations” plus:
• Hardwire Magnetic Contact (13-068 or 13-071) or Wireless Learn Mode Door/Window Sen-
sor (60-362)
• Siren Timeout set to 5 minutes or more
Residential Fire Warning System Control Unit (ULC-S545-M89)
Basic system as described for “UL 985 Listed Installations” plus:
• Hardwire Smoke Detector: System Sensor models 2400 or 2400TH learned into Sensor
Group 26, or Sentrol (ESL) models 429AT, 521B, or 521BXT learned into sensor group 26
• Wireless Smoke Sensor 60-506-319.5 or 60-848-02-95 learned into sensor group 26
• Immediate Trouble Beeps set to on
Note
For 24-hour backup, exter-
nal power drain is limited to
90 mA (during normal
standby condition) using a
4.5 Ah battery, or 190 mA
continuous using a 7.0 Ah
battery.
• RF TX Timeout set to 4 hours (if system includes SuperBus 2000 RF Transceiver and wire-
less smoke sensors)
• Siren timeout set to 5 minutes or more.
California State Fire Marshall Listed Installations
Same as Household Fire Warning System (UL 985), plus:
• SMOKE VERIFY must be set to off
Planning the
Installation
This section describes system capabilities to help you get familiar with the system. “Appendix
A” provides planning sheets with tables that let you record the hardware and programming con-
figuration of the system. Fill in all necessary information ahead of time to help prepare for sys-
tem installation.
The panels have the following capabilities:
Standard Panel
The following describe the basic panel (out-of-box) hardware capabilities.
• Power: Input for an AC step-down, plug-in style transformer.
• Auxiliary Power Output: Output that supplies 9 to 14 VDC with up to 1 amp for bus
devices and hardwired detectors, such as smoke and motion detectors.
Capabilities Concord Express V4
Concord 4/Concord
Commercial V4
Zones 32 96
Partitions 1 6
Bus Devices 16 16
User Codes 16 230
