Concord 4 Series Systems
1
About This
Manual
This manual provides information for planning, installing, programming, and testing this security
system. When necessary, this manual refers you to other documentation included with compati-
ble peripherals.
Planning sheets are included for you to record hardware layout and software programming set-
tings.
About the User’s Guide
The User’s Guide (466-2183) contains user worksheets that should be filled out during the instal-
lation and programming of the system. For multi-partition systems, a User’s Manual for each
partition is suggested.
Special Installation Requirements
This security system can be used as a fire warning system, an intrusion alarm system, an emer-
gency notification system, or any combination of the three.
Some installations may require configurations dictated by city/state codes, insurance, or Under-
writer’s Laboratories (UL). This section describes the various component and configuration list-
ings.
UL Listed Installations
This section describes the requirements for UL Listed installations.
Basic System
• Control Panel (600-1021-95R Concord 4 RF, 600-1022-95R Concord Express V4, 600-1040
Concord Commercial V4, or 600-1042 Concord 4 Hybrid)
• Standard Class II 16.5 VAC, 40 VA power transformer 22-145 (order #600-1023) or 22-
145-CN (order #600-1023-CN), or Power Line Carrier Class II 16.5 VAC, 40 VA power
transformer 22-149 (order #600-1024) or 22-149-CN (order #600-1024-CN). These trans-
formers must be ordered separately from GE Security.
• Backup Battery 12V 4.5 Ah (60-681) or 12V 7 AH (60-680)
•SuperBus
®
2000 Fixed Display Touchpad (60-820), 2x16 LCD Touchpad (60-746-01),
ATP1000 (60-983) ATP2100 (60-985), ATP 2600 (60-984), 2x20 LCD Touchpad (60-803),
or 2x20 VFD Touchpad (60-804)
• Interior Speaker Siren (60-528), Hardwire Interior Siren (13-949), or Speaker Siren (13-060)
Basic system may also include a SuperBus 2000 RF Receiver (60-764-95R-01) or a SuperBus
Transceiver (600-1025-01-95R).
Household Burglary Alarm System Unit (UL 1023)
Basic system, plus:
• Hardwire Magnetic Contact (13-068 or 13-071) or Wireless Learn Mode Door/Window Sen-
sor (60-362)
• Immediate Beeps set to on
• UL 98 Options set to on
• Receiver Failure set to on (if wireless devices are used)
• Siren Verify set to on
• Exit Delay set to 60 seconds
• Quick Exit set to off
• Siren Timeout set to 4 minutes or more
• Entry Delay set to 45 seconds or less
• RF TX Timeout set to 24 hours (if system includes a built in receiver or SuperBus 2000 RF
Receiver or SuperBus 2000 RF Transceiver and wireless burglary sensors)
• Extended Delay set to off
• Sleep Time set to off
• Two Trip Error set to off
• Alarm Verify set to off
• Disable Trouble Beeps set to off
