Concord 4 Series Systems
51
The following describes the settings that appear under SIREN OPTIONS—PARTITION 1.
Sensors Menu
The SENSORS menu gives you access to the following settings:
•
LEARN SENSORS lets you add (learn) hardwire zones, wireless sensors, and wireless touch-
pads into panel memory.
•
SENSOR TEXT lets you “name” the sensors and zones you have added to the system.
•
DELETE SENSORS lets you delete zones and sensors from panel memory.
•
EDIT SENSORS lets you view and, if desired, change a sensor group or partition assignment.
You can also identify whether a zone is wireless or hardwire, whether it is configured as
Normally Closed (N/C) or Normally Open (N/O), or if the zone is a touchpad.
UL 98 Options (0702)
Siren Options-Global (Default = off)
This setting determines whether the panel complies with UL 98
requirements (4-hour trouble beep restart, 4-hour backup battery test,
4-hour smoke (group 26) zone supervisory).
Note
For UL Listed installations, this feature must be on.
To turn UL 98 Options off or on:
1. With the display showing UL 98 OPTIONS OFF/ON
(current setting), press 1 (off) or 2 (on). The dis-
play flashes the entered setting.
2. Press # and the display shows the new setting.
Global Fire (0703)
Siren Options-Global (Default = off)
This setting determines whether or not sirens in all partitions sound
(on) if any partition activates a fire alarm.
To turn Global Fire off or on:
1. With the display showing GLOBAL FIRE OFF/ON
(current setting), press 1 (off) or 2 (on). The dis-
play flashes the entered setting.
2. Press # and the display shows the new setting.
Silent Panic (0704)
Siren Options-Global (Default = off)
This setting determines whether touchpad police panic alarms are
audible (off) or silent (on).
To turn Silent Panic off or on:
1. With the display showing GLOBAL SILENT PANIC
OFF/ON
(current setting), press 1 (off) or 2 (on).
The display flashes the entered setting.
2. Press # and the display shows the new setting.
Siren Verify (0710)
Siren Options-Partition 1 (Default = off)
This setting determines whether or not the panel supervises the panel
speaker terminals (7–8). When this feature is on, the panel will indicate a
trouble condition if no speaker is connected to panel speaker terminals.
Note
For UL Listed installations, Siren Verify must be set to on.
To turn Siren Verify off or on:
1. With the display showing SIREN VERIFY OFF/
ON
(current setting), press 1 (off) or 2 (on).
The display flashes the entered setting.
2. Press # and the display shows the new setting.
Table 6: How to Trip Sensors
Sensor Steps to Trip Sensor
Hardwire Zones
Start with the zone in its “normal” state, then trip the zone into
its alarm state. A normally closed door, for example, should be
closed when you begin the Learn Sensors process. To trip the
zone, open the door.
Wireless Sensors Follow the instructions included with each sensor.
