GE Concord 4 Series Installation Instructions

Concord 4 Series Systems 2
Household Fire Warning System (UL 985)
Basic system, plus:
• Hardwire Smoke Detector: System Sensor models 2400 or 2400TH learned into sensor group
26 or Sentrol (ESL) models 429AT, 521B or 521BXT learned into sensor group 26
• Wireless Smoke Sensor 60-506-319.5 or 60-848-02-95 learned into sensor group 26
• Immediate Beeps set to on
• UL 98 Options set to on
• Receiver Failure set to on (if wireless devices are used)
• Siren Verify set to on
• RF TX Timeout set to 4 hours (if system includes a built in receiver or SuperBus 2000 RF
Transceiver and wireless smoke sensors)
• Sleep Time set to off
• Siren Timeout set to 4 minutes or more
• Two Trip Error set to off
• Disable Trouble Beeps set to off
UL 1023 & 985 24-Hour Backup
For 24-hour backup, the total current draw for all connected devices is limited to 90 mA (during
normal standby conditions) using a 4.5 Ah battery, or 190 mA (during normal standby condi-
tions) using a 7.0 Ah battery.
SIA System Requirements
Note
UL requirements take prior-
ity over SIA requirements.
SIA system requirements are the same as those described for a UL Listed Basic System on page
1, plus:
• If multiple annunciation is required, use additional touchpads. Model numbers 60-746-01,
60-803, 60-804, 60-820, 60-983, 60-984, 60-985.
SIA Setting Requirements
The following table describes programming requirements to meet ANSI-SIA CP-01.
Shortcut # Function Programming
Page
Reference
Testing
Page
Reference
Default
Setting
Required Setting
0013 - 0063 Exit Extension 29 70 On On
0016 - 0066 Duress Code 30 70 Disabled Disabled
02006 Dialer Abort Delay 35 70 30 Sec. 15-45 sec.
02007 Cancel Message 36 70 On On
02009 Call Wait Cancel 36 70 Disabled On if reporting to central station and
customer has call waiting service
0310 - 0360 Entry Delay 40 70 30 sec. 30-240 sec.
0311 - 0361 Exit Delay 40 70 60 sec. 45-184 sec.
06015 Swinger Limit 46 70 1 1
1100 Smoke Verify 58 70 Off On if smoke alarms are programmed
into system
N/A Cross Zoning 91 70 Disabled Enabled for zones with a high
probability of false alarms
WWW.DIYALARMFORUM.COM

GE Concord 4 Series Specifications

General

User Codes	230
Backup Battery	12V 4Ah rechargeable battery
Wireless Frequency	319.5 MHz
Communication	POTS, optional cellular and IP modules
Wireless Capability	Yes
Keypad Options	Multiple keypad options including touchscreen
Wired Zones	8 on board
Power Supply	16.5 VAC Transformer
Compatibility	Compatible with GE Security wireless sensors
Zones	Up to 96
Event Buffer	512
