MDS 05-6632A01, Rev. F MDS Orbit MCR/ECR Technical Manual 135
 Last RSSI – The RSSI measured at the time of the last received packet.
Last Error Vector Magnitude – The EVM measured at the time of the last received packet. For more
information, refer to Important Notes and Information Regarding EVM
 Last Modulation – The modulation measured at the time of the last received packet.
 Rate – The calculated over the air rate from Table 3-15.
Figure 3-70 Licensed Narrowband (LN) Hardware Info
Information about the Licensed Narrowband NIC’s hardware is also displayed on the LN Radio’s
Statistics menu. This information may be helpful when calling technical support.
Connections Status (AP Only)
In AP mode the “Connected Remotes” and “Endpoints” information will be displayed in addition to the
Active Channel.
NOTE Clicking on the MAC address in either Connected Remotes or Endpoints will bring up more
stats.
NOTE Highlighting a MAC address of a Connected Remote and clicking Remote Web Connect will
open a remote web UI session to the selected remote. See Section 3.8.16, Remote Management
Service, for more information.
Figure 3-71. Licensed Narrowband (LN) AP Connection Status
Last RX Packet
Hardware Info
