34 MDS Orbit MCR/ECR Technical Manual MDS 05-6632A01, Rev. F
Table 2-8. Signal Loss In Coaxial Cables (at 900 MHz)
Cable Type
10 Feet
(3 Meters)
50 Feet
(15 Meters)
100 Feet
(30.5 Meters)
500 Feet
(152 Meters)
RG-214
0.76 dB
3.80 dB
7.60 dB
Unacceptable Loss
LMR-400
0.39 dB
1.95 dB
3.90 dB
Unacceptable Loss
1/2 inch HELIAX
0.23 dB
1.15 dB
2.29 dB
11.45 dB
7/8 inch HELIAX
0.13 dB
0.64 dB
1.28 dB
6.40 dB
1-1/4 inch HELIAX
0.10 dB
0.48 dB
0.95 dB
4.75 dB
1-5/8 inch HELIAX
0.08 dB
0.40 dB
0.80 dB
4.00 dB
Accessories and Spares
The table below lists common accessories and spare items for use with the MCR. GE MDS also offers an
Accessories Selection Guide listing an array of additional items that may be used with the product.
Contact your factory representative or visit www.gemds.com to obtain a copy of the guide.
Table 2-9. Accessories & Ancillary Items
Item
Description
Part Number
DC Power Plug, 2-pin, polarized
Mates with power connector on the
unit’s case. Screw terminals are
provided for wires, threaded locking
screws to prevent accidental
disconnect.
73-1194A53
Setup Guide
(for installation instructions)
Describes the installation and setup
of the unit. It is a companion to this
Technical Manual. PDF copy
available free at www.gemds.com.
05-6709A01
Flat Mounting Bracket Kit
Brackets that attach to the bottom
of the unit, used for mounting to a
flat mounting surface.
03-4123A14
COM Port Adapter
Converts the unit’s RJ-45 serial jack
to a DB-9F type.
73-2434A25
Mini USB 2.0 Cable, 3 ft
USB Type A (M) to mini-USB Type
B (M) cable to provide console
access through the radio’s mini
USB connector.
97-6694A05
DIN Rail Mounting Kit
Hardware for DIN Rail Mounting
03-4125A06
