MDS 05-6632A01, Rev. F MDS Orbit MCR/ECR Technical Manual 201
Figure 3-106. VLAN Creation
 Type – Interface type to be created. In this case, choose Vlan.
 Name - The name of the interface. Up to 48 characters.
Configure the newly created VLAN
After clicking the OK button on the pop-up in Creation will automatically take the configuration screen
for that interface, or click on the new interface located in the Interfaces navigation section.
 Description - User defined identifier for the this connection up to 34 characters
 Enabled - Checked indicates enabled (DEFAULT). Disable will prevent usage.
Scroll down and set the VLAN ID
