174 MDS Orbit MCR/ECR Technical Manual MDS 05-6632A01, Rev. F

 URL - For HTTP, the location of the source file

 Server Address - For FTP, TFTP, and SFTP, the remote server's host name or IP address

 File Path - For FTP, TFTP, and SFTP, the path to the source file on the remote server

 User Name - For FTP and SFTP, the user name on the remote server

 Password - For FTP and SFTP, the password on the remote server

 Control Port - For FTP, the TCP control port (advanced setting - use default)

 Data Port - For FTP, the TCP data port (advanced setting - use default)

 Block Size - For TFTP, the block size as defined in RFP 2348 (advanced setting - use default)

 Timeout - For FTP, TFTP, and SFTP, the timeout in seconds (advanced setting - use default)

The following example shows how to have the device download a firmware image (named mcr-bkrc-

4_0_2.mpk) from a TFTP server running on a host (address 192.168.1.10) that is accessible from the

MCR (e.g. a locally connected host or remote host accessible via cellular interface). To start

reprogramming the inactive firmware image from the CLI, enter the following command to download the

firmware image from the TFTP server:

> request system firmware reprogram filename mcr-bkrc-4_0_2.mpk manual-file-server { tftp {

address 192.168.1.10 } }

Monitoring - Reprogram

Once the reprogramming is begun, the process may be cancelled by clicking the Cancel

Reprogramming button. The current status of the reprogramming process is displayed on the web page.

Note that the web page does not display the current status if the device has not been instructed to

reprogram (in other words, if the state is “inactive”).

Figure 3-88. Reprogram Inactive Image Monitoring

The reprogramming status contains the following items:

 Current State – The status of the reprogramming task:

- inactive

- transfering

- processing
