MDS 05-6632A01, Rev. F MDS Orbit MCR/ECR Technical Manual 185
 Control Port - For FTP, the TCP control port (advanced setting - use default)
 Data Port - For FTP, the TCP data port (advanced setting - use default)
 Block Size - For TFTP, the block size as defined in RFP 2348 (advanced setting - use default)
 Timeout - For FTP, TFTP, and SFTP, the timeout in seconds (advanced setting - use default)
The following example shows how to have the device download a configuration file (named config-2016-
02-04.xml) from a TFTP server running on a host (address 192.168.1.10) that is accessible from the MCR
(e.g. a locally connected host or remote host accessible via cellular interface). To start the configuration
file import from the CLI, enter the following command to download the configuration from the TFTP
server:
> request system configuration-files import filename config-2016-02-04.xml manual-file-
server { tftp { address 192.168.1.10 } }
Monitoring - Import
Once the import of a configuration file is begun, the process may be cancelled by clicking the Cancel
Import button. The current status of the import process is displayed on the web page. Note that the web
page does not display the current status if the device has not been instructed to import a configuration file
(in other words, if the state is “inactive”).
Figure 3-97. Import Configuration Monitoring
The import status contains the following items:
 Current State – The status of the import task:
- inactive
- transfering
- processing
- cancelling
- complete
- failure
- cancelled
 Detailed Message – The details regarding the operation, such as “Transferring configuration
file”
 Size – The total number of bytes in the file (not displayed on the web UI)
