18 MDS Orbit MCR/ECR Technical Manual MDS 05-6632A01, Rev. F
Bolded font example (used to show tables displayed on a PC screen)
In the Device Management section of this manual (Page 36), there are a number of command strings
where information is presented by the unit and a reply is required from the user. In such cases,
information from the unit is shown in a non-bolded font and the user response is shown in bold. For
example:
(none) login: admin
Further, in some cases, command lines will be shown with non-bolded, italicized text contained within
the string. Such text indicates the need for user-supplied variable parameters, such as the name of an item.
For example:
% set interfaces interface myBridge type bridge
In the above example, you would enter the specific name of your bridge to complete the entry.
NOTE The LAN port should be assigned IP addresses only if it is a routed interface (that is, not in a
bridge).
NOTE The software commands and responses shown in this manual were obtained from a unit
operating in a lab environment. The information displayed may differ from field service
conditions.
