Chapter 5 Detailed Descriptions of I/O Modules
GFK-2958E RSTi-EP User Manual 97
Process Data Inputs EP-1214
Byte
Bit
Description
IB0
IX0.0
DI0
IX0.1
DI1
IX0.2
DI2
IX0.3
DI3
IX0.4
reserved
IX0.5
reserved
IX0.6
reserved
IX0.7
reserved
5.2 Digital Input Module EP-1218
Digital Input Module EP-1218 Connection Diagram EP-1218
The digital input module EP-1218 can detect up to 8 input signals. Two sensors can be connected to
each connector using a 2-wire connection. A status LED is assigned to each channel. The module
electronics supply the connected sensors with power from the input current path (I
IN
).
