Overview of Editable Parameters EPXPNS001
Parameter
Optional values
Default
IP address
†
4 numbers between 0 and 255
Subnet mask
4 numbers between 0 and 255
Gateway
4 numbers between 0 and 255
Webserver via Ethernet
disabled / enabled
disabled
IP address USB port
192.168.1.202; 192.168.2.202, 192.168.3.202,
192.168.4.202, 192.168.5.202
192.168.1.202
Process alarm
disabled / enabled
disabled
Diagnostic alarm
disabled / enabled
disabled
Type of diagnostic
Extended channel diagnostic (short
diagnostic)
Manufacturer-specific diagnostic (complete
diagnostic)
Extended channel diagnostic
(short diagnostic)
Behavior of outputs on fieldbus
errors
All outputs off / Enable substitute value / Hold
last value
All outputs off
Module behavior on hot swap
Continue data exchange /
Behavior like fieldbus error
Continue data exchange
Data format
Motorola / Intel
Motorola
Lock force mode
Force mode unlocked / Force mode locked
Force mode unlocked
†
Change requires restart of the network adapter.
4.2.4 Supported Modules and Power Supplies
The following modules can be used with this release of the RSTi-EP PROFINET Network Adaptor:
Catalog Number
Module Description
Digital Input Modules
EP-1214
Digital Input, 4 Points, Positive Logic 24VDC, 2,3, or 4 Wire
EP-1218
Digital Input, 8 Points, Positive Logic, 24VDC 2 Wire
EP-1318
Digital Input, 8 Points, Positive Logic, 24VDC 3 Wire
EP-125F
Digital Input, 16 Points, Positive Logic, 24VDC, 1 Wire
EP-12F4
Digital Input, 4 Points, Positive Logic 24VDC, 2,3, or 4 Wire, Time stamp
EP-1804
Digital Input, 4 Points 110/230 VAC (65 – 277 VAC), 2 Wire, Isolated
Digital Output Modules
EP-2214
Digital Output, 4 Points, Positive Logic 24VDC, 0.5A, 2,3, or 4 Wire
EP-2614
Digital Output, 4 Points, Positive Logic 24VDC, 2.0A, 2,3, or 4 Wire
EP-2634
Digital Output, 4 Points, Positive/Negative Logic 24VDC, 2.0A, 2,3, or 4 Wire
EP-2218
Digital Output, 8 Points, Positive Logic, 24VDC, 0.5A, 2 Wire
EP-225F
Digital Output, 16 Points, Positive Logic, 24VDC, 0.5A, 1 Wire
Digital Relay Output Modules
EP-2714
Digital Relay Output, 4 Points, Positive Logic, 24 - 220 VDC/VAC, 6A, 2 Wire
EP-2814
Solid-state Relay Output Module
