Chapter 4 Detailed Descriptions of the Fieldbus Network Adapters
GFK-2958E RSTi-EP User Manual 72
4.3.3 Specifications
EPXETC001
System data
Connection
2 x RJ-45
Fieldbus protocol
EtherCAT
Process image
Process data
max. 1024 bytes
Parameter data
max. 64*64 = 4 KB
Diagnostic data
max. 64*50 = 3200 bytes
Number of modules
max. 64 active
Configuration interface
Micro USB 2.0
Transfer rate
Fieldbus
Max. 100 Mbps
RTSi-EP system bus
Max. 48 Mbps
Supply
Supply voltage for system and inputs
20.4V – 28.8V
Supply voltage for outputs
20.4V – 28.8V
Max. feed-in current for input modules
10 A
Max. feed-in current for output modules
10 A
Current consumption from system current path
I
SYS
110 mA
Connection data
Type of connection
Spring style
Conductor cross-section
Single-wired, fine-wired
0.14 – 1.5 mm
2
(AWG 26 – 16)
General data
Operating temperature
-20°C to +60°C (-4 °F to +140 °F)
Storage temperature
-40°C to +85°C (-40 °F to +185 °F)
Air humidity (operation/transport)
5% to 95%, noncondensing as per IEC 61131-2
Width
52 mm (2.05 in)
Depth
76 mm (2.99 in)
Height
120 mm (4.72 in)
Weight
227 g (8 oz)
Configuration
ESI file is available on the Support website http://support.ge-ip.com
for download and import into Programmer Tool which supports
EtherCAT. The ESI supporting a firmware release is part of the firmware
upgrade kit available on the Support website.
Overview of the Editable Parameters EPXETC001
Parameter
Optional values
Default
IP address USB port
†
192.168.1.202; 192.168.2.202, 192.168.3.202,
192.168.4.202,
192.168.5.202
192.168.1.202
Process alarm
disabled / enabled
disabled
Diagnostic
disabled / enabled
disabled
Behavior of outputs on fieldbus error
All outputs off / Enable substitute value/ Hold last
value
All outputs off
Module behavior on hot swap
Continue data exchange / behavior like fieldbus error
Continue data
exchange
Data format
Motorola / Intel
Motorola
Webserver via Ethernet
disabled / enabled / enabled
disabled / enabled
Coupler control
Reserved
Off
†
Change requires restart of the network adapter.
