Chapter 4 Detailed Descriptions of the Fieldbus Network Adapters

GFK-2958E RSTi-EP User Manual 71

Caution

In the case of a maximum power supply of >8 A and a maximum

temperature of > +55°C 131 °F, all four contacts must be connected with

1.5 mm² wiring.

EPXETC001

Block Diagram EPXETC001
