Chapter 5 Detailed Descriptions of I/O Modules
GFK-2958E RSTi-EP User Manual 113
Specifications EP-125F
System data
Data
Process, parameter and diagnostic data depend on the network
adapter used (refer to the table in the section, Order and
Arrangement of the Modules)
Interface
RSTi-EP I/O communication bus
System bus transfer rate
48 Mbps
Inputs
Number
16
Sensor types
Type 1 and Type 3 sensors as per IEC 61131-2
Input filter
Input delay 3 ms
Low input voltage
< 5 V
High input voltage
> 11 V
Sensor supply
No
Sensor connection
1-conductor
Reverse polarity protection
Yes
Module diagnosis
Yes
Individual channel diagnosis
No
Supply
Supply voltage
20.4V – 28.8V
Current consumption from system current path
I
SYS
8 mA
Current consumption from input current path I
IN
52 mA
General data
Weight
87 g (3.07 oz)
