Chapter 5 Detailed Descriptions of I/O Modules
GFK-2958E RSTi-EP User Manual 221
Overview of the Editable Parameter EP-5311
Channel
Description
Options
†
Default
0
Delay time
1 μs (0) / 2 μs (1) / 4 μs (2) / 8 μs (3) / 16 μs (4) /
32 μs (5) / 48 μs (6) / 64 μs (7)
64 μs
0
SSI transfer rate
125 kHz (0) / 250 kHz (1) / 500 kHz (2) / 1 MHz
(3) / 1,5 MHz (4) / 2 MHz (5)
125 kHz
0
Number of indicator bits
0 ... 15
0
0
Number of frame data bits
8 Bit (0) / 9 Bit (1) / 10 Bit (2) / ... / 31 Bit (23) / 32
Bit (24)
25 Bit
0
SSI mode
Listening (0) / Master (1)
Master
0
Bit order
MSB first (0) / LSB first (1)
MSB first
0
Data evaluation at edge
1 to 0 (0) / 0 to 1 (1)
1 to 0
0
Data format
Binary (0) / Gray-Code (1)
Gray-Code
0
SSI interface
Disabled (0) / enabled (1)
Disabled
†
Values in brackets for Modbus-TCP and EtherCAT
