GFK-2958E RSTi-EP User Manual 51
Digital Output, 8 Points, Positive Logic,
24VDC, 0.5A, 2 Wire
Digital Output, 16 Points, Positive Logic,
24VDC, 0.5A, 1 Wire
Digital Output, 4 Points, Positive Logic, 230
VAC, 0.5A
Digital Relay Output, 4 Points, Positive
Logic, 24 - 220 VDC/VAC, 6A, 2 Wire
1 Channel High Speed Counter, AB
100 kHz 1 DO 24VDC, 0.5A
2 Channel High Speed Counter, AB
100 kHz
2 Channel Frequency Measurement,
100 kHz
1 Channel Serial Communications, 232,
422, 485
1 Channel SSI Encoder, BCD or Gray-Code
Format, 5/24 VDC
2 Channels PWM Output, Positive Logic,
24VDC, 0.5 A
2 Channels PWM Output, Positive Logic,
24VDC, 2 A
Analog Input, 4 Channels Voltage/Current
16 Bits 2, 3, or 4 Wire
Analog Input, 4 Channels Voltage/Current
16 Bits with Diagnostics 2, 3, or 4 Wire
Analog Input, 4 Channels Voltage/Current
12 Bits 2, 3, or 4 Wire
Analog Input, 4 Channels TC 16 Bits with
Diagnostics 2, 3, or 4 Wire
Analog Input, 8 Channels Current 16 Bits 2,
3, or 4 Wire
Analog Input, 8 Channels Current 16 Bits 2,
3, or 4 Wire, Channel Diagnostic
Analog Output, 4 Channels Voltage/
Current 16 Bits 2, 3, or 4 Wire
Analog Output, 4 Channels Voltage/
Current 16 Bits with Diagnostics 2, 3, or
4 Wire
Analog Input, 4 Channels RTD 16 Bits with
Diagnostics 2, 3, or 4 Wire
1 Safe Feed-Input, 24 VDC
2 Safe Feed-Inputs, 24 VDC,
Programmable Delay
2 Safe Feed-Inputs, 24 VDC
