Chapter 4 Detailed Descriptions of the Fieldbus Network Adapters
GFK-2958E RSTi-EP User Manual 59
Overview of Editable Parameters EPXPBS001
Parameter
Additional explanations
Optional values
Default
IP address USB port
192.168.1.202; 192.168.2.202,
192.168.3.202, 192.168.4.202,
192.168.5.202
192.168.1.202
DP-Alarm mode
V0 / V1
V1
DP alarm mode V0
For mode V0, the alarm triggers are set in the parameter data.
Diagnostic alarm
These switches are always
selectable, but they only have a
function in mode V0. Diagnostic
messages are generated which
are not acknowledged by the
PLC.
enabled / disabled
disabled
Process alarm
enabled / disabled
disabled
Hot-plug alarm
enabled / disabled
enabled
DP alarm mode V1
In mode V1, the alarm triggers are set in the engineering environment.
Diagnostic alarm
These switches can be selected
only in mode V1, in V0 they are
inactive. Diagnostic messages
are generated which are
acknowledged by the PLC.
enabled / disabled
disabled
Process alarm
enabled / disabled
disabled
Hot-plug alarm
enabled / disabled
enabled
Identifier-related diagnosis
A diagnostic block is attached to
the diagnostic message.
enabled / disabled
enabled
Channel-related diagnosis
A diagnostic block is attached to
the diagnostic message.
enabled / disabled
enabled
Module status
A diagnostic block is attached to
the diagnostic message.
enabled / disabled
enabled
Data format
Motorola / Intel
Motorola
Output behavior fieldbus
error
All outputs off / activate
replacement values / retain last
value
All outputs off
Module behavior on hot
swap
Continue data exchange /
behavior as with fieldbus error
Continue data
exchange
Change requires restart of the network adapter.
