GEDA 200Z - Speeds; Electrics; Assembly Height; Lifting Height; Emissions

Rack and pinion hoist
Assembly and Operating Instructions
30 / 100 BL108 GB Edition 03.2018 Rev. 02
3.4.2 Speeds
Lifting speed
Construction hoist approx. 25 m/min.
Safety gear
Triggering speed (V
max
) 44 m / min.
3.4.3 Electrics
Base unit
Operating voltage 230 V / 50 Hz / 3 x 16 A / 1 Ph
Protection class IP 54 (NEMA 3)
Drive
230 V / 50 Hz
Capacity 1.7 kW
Current consumption 11 A
Start-up current (max.) approx. 35 A
Switch-on period (ED) S3 (60 %)
3.4.4 Assembly height / Lifting height
Max. assembly height 41 m
Assembly height
Delivery height
37 m
35 m
41 m
39,8 m
3.4.5 Emissions
Sound level < 78 L
PA
