GEDA 200Z - Fault Table

Rack and pinion hoist
Assembly and Operating Instructions
83 / 100 BL108 GB Edition 03.2018 Rev. 02
9.1 Fault table
In the following table you will find potential faults and the appropriate
remedial action.
Fault
Cause
Remedial action
Load platform does
not move
Fuses in the building site
main cabinet okay
Mains plug disconnected
Main switch off
Fuses in the trolley switch
box okay
EMERGENCY STOP button
(car control) pressed
Loading ramp open
Load platform rotated
outwards
Assembly protection bar
activated
Safety gear engaged
Check/correction
Connect mains plug
Switch on the main switch
Check/correction
Unlock the EMERGENCY
STOP button
Close the loading ramp
Turn platform inwards
Release the assembly
protection bar
Release safety gear (refer to
Chapter 8.5.2)
Load platform only
moves upwards
The DOWN button on the
control functions
Is the DOWN limit switch
functional
Check DOWN button/replace
control
Check/replace the DOWN
limit switch
Load platform only
moves downwards
The UP button on the control
functions
If the UP limit switch
functions
Check UP button/replace
control
Check/replace the UP limit
switch
Red control light
illuminates and
alarm signal sounds
Overload protection has
triggered
Reduce the load
Motors do not
generate full power
Voltage drop of more than
10%
Select a supply cable or
extension cable with a
greater cross section
Load platform
moved too high
(refer to
Chapter 9.1.2)
UP limit switch defective
Fault in the electrical system
Check/replace UP limit switch
Check system
Load platform
moved too low
(refer to
Chapter
9.1.3)
DOWN limit switch defective
Fault in the electrical system
Brake air gap is too large
Check/replace DOWN limit
switch
Check system
Adjust air gap
