3.6 Requirements of the installation site
3.6.1 Foundation
• The foundation must be horizontal and have sufficient load bearing
capacity.
− The foundation must be compacted according to the ground load
[kN/m²] (refer to assembly height).
• Depending on the assembly height, for example, wooden planks or
steel sheeting, can be used as load distributing base supports.
3.6.2 Soil pressure
• The total weight (see table) of the hoist and ladder sections are
transferred to the foundation via the foot section support under the
ladder track.
− Overall weight (cmpl. with rail brackets).
Load capacity:
200 kg
Mass per ladder section:
24 kg
Length per ladder section:
2.0 m
Height of base unit:
2.0 m
Empty weight of the base unit with load
platform:
approx. 205 kg
Base area without base support
Base area with support
(e.g.: 20cm x 70cm board)
0.022 m²
0.140 m²
Assembly height
in m
6
10
15
20
25
30
35
41
Number of ladder
sections required
2
4
7
9
12
14
17
20
Total weight (kg)
450
495
550
605
660
715
770
854
Ground pressure
without sole plate
(kN/m²)
204
224
249
274
299
324
349
382
Ground pressure with
sole plate (kN/m²)
32
35
39
43
47
51
55
60
