Waveform tab
The waveform tab is by default always
selected at the start of a patient case.
The order and number of displayed waveforms
can be modified at any time using the screen
layout membrane button. A maximum of six
waveforms can be displayed.
Any modified settings revert to default when
the patient case is ended. Default set-up is
selected during system installation.
The Pressure waveform is mandatory and
always displayed at the top of the waveform
display area.
Displayed gas waveforms have a four second
delay, and are thus not synchronized with the
pressure, flow or volume waveforms.
The following information can be displayed as
waveforms:
• Pressure
• Flow
• Volume
• FiAA
• etCO
2
• etO
2
108
FLOW-i 4.2, User's Manual
| 5
| System functionality |
