5. Remove the two absorber valves (turn
counter-clockwise) in the order shown in
the picture. Attach these to a metal
framework.
1
6. Be careful not to damage the expiratory
outlet one way valve located at the back
of the cassette.
7. Remove and replace the pressure sensor
filters array (left) and gas sampling filters
array (right) according to hospital routines.
Newer systems are not equipped with the gas
sampling filters array. Do not remove the
protective covers replacing the array.
FLOW-i 4.2, User's Manual
241
| Routine cleaning and maintenance |
12 |
