Getinge Maquet FLOW-i 4.2 User Manual

DescriptionSymbol
Medical device maximum weight
(C20 with three drawers). C30
and C40 are lighter, see
technical specifications, page
266.
365 kg
Red circle with a single red line
over a black drawing. Pushing
prohibited
Red circle with a single red line
over a black drawing. Stepping
prohibited
Red circle with a single red line
over a black drawing. Sitting
prohibited
Lift button, 10% lift dutycycle,
for more information see Chapter
7, page 146.
>
18
<
2
Manual (MAN) ventilation
Automatic (AUTO) ventilation
Manual breathing bag
connection
Y-piece connection for System
checkout
Equipotentiality terminal.
Mains power On Off button
DescriptionSymbol
CO
2
absorber connected and
locked in position
CO
2
absorber bypassed
CO
2
absorber unlocked,
vaporizer unlocked,
patient cassette unlocked,
wheel brake unlocked
Wheel brake locked
Labelled part may be disinfected
using a steam autoclave
Autoclavable
Use centre of floating ball as
reference when reading from the
Auxiliary O
2
flow scale
Inspiratory connection to the
patient cassette
Insp.
Expiratory connection to the
patient cassette
Exp.
O
2
flow meter/suction equipment
O
2
flush
0
2
+
Anesthesia Gas Scavenging
AGS
Home touch pad symbol, see
Chapter 9, page 162
FLOW-i 4.2, User's Manual
33
| System overview |
3 |
