Getinge Maquet FLOW-i 4.2

DescriptionSymbol
Timer touch pad symbol, see
Chapter 9, page 162
Emergency ventilation
Emergency
ventilation
Not for use with AFGO.
Emergency O
2
flow is always
delivered through the patient
cassette.
Not for use with AFGO
N
2
O inlet pressure range:
250-650 kPa/2.5-6.5 bar/36-94
PSI
N O
2
2 . 5 - 6.5 k Pa x 10 0
( 3 6 - 94 p s i )
AFGO Max 120 mbar/cmH
2
O
Reading lamp
Cylinder gas inlet
Backup gas system pressure
increase/decrease
RS232 serial port
RS232
Gas supply inlet
Gas supply outlet
Network connection
DescriptionSymbol
Data communication
input/output ports
Fuse
Control panel connection
VGA connection
USB connection
34
FLOW-i 4.2, User's Manual
| 3
| System overview |
