Control interfaces

Maquet PowerLED II

IFU 01811 EN 10

37 / 116

3 Control interfaces

2 3

Fig.29: PWD II control interfaces

1 Lighthead control keypad

2 Touchscreen control panel (optional)

3 Wall-mounted control keypad (optional)

NOTE

The light can also be controlled via external control equipment provided by an in-

tegrator. Contact your Getinge representative for more information. Contact your

Getinge representative for more information.
