4
Use
Controlling the light
60 / 116
Maquet PowerLED II
IFU 01811 EN 10
4.2.8 Presets (with touchscreen control panel only)
4.2.8.1 Selecting or storing a preset
2
3
4
1
Fig.61: Presets page
Applying a preset
1. Press Presets 1 to access the Presets page.
Ø The presets page is displayed.
2. Press the Apply preset 2 button for the desired preset name 4 corresponding to of the six
saved presets.
Ø The selected preset is applied.
5
6 7
8
Fig.62: Store preset
Storing a preset
1. Adjust the light settings to the configuration desired for the preset.
2. Press Store preset 3 .
Ø The preset data entry window is displayed (see opposite) showing the selected preset 5 .
