8
Technical specifications
Optical specifications
104 / 116
Maquet PowerLED II
IFU 01811 EN 10
8 Technical specifications
8.1 Optical specifications
Specifications Maquet
PowerLEDII700
Maquet
PowerLEDII500
Tolerance
Illumination 15,000 lux to 160,000 lx 
Nominal illumination (Level10) 130,000lx ±10%
Illumination with Boost mode (Level11) 160,000 lx 0/-10%
Central illumination (AIM enabled)
3
130,000lx ±10%
Diameter d10
4
13 / 20 / 27 cm 13 / 20cm ±2 cm
Diameter d50/d10 0.56 ±0.06
Illumination depth at 60% 24 / 43 / 44 cm 38 / 53 cm ±10%
Fixed colour temperature
5
3,800K / 4,300K ±400ºK
Colour rendering index (Ra) 96 ±4
Special colour rendering index (R9) 90 ±10
Special colour rendering index (R15) 95 ±5
Radiant energy 3.5 mW/m²/lx ±0.4
Irradiance (Ee)
4
< 500 W/m² 
UV illumination ≤ 0.5 W/m² 
FSP system Yes 
Illumination in ambient light mode < 500lx 
Tab.36: Table of optical data for Maquet PowerLEDII700 and Maquet PowerLEDII500 lightheads
3
For all light field diameters
4
In nominal mode
5
The colour temperature is selected at the time of order
