Getinge Maquet PowerLED II User Manual

3
Control interfaces
Touchscreen control panel
40 / 116
Maquet PowerLED II
IFU 01811 EN 10
3.3 Touchscreen control panel
1
2
3
Fig.32: Touchscreen control panel
1 Status bar
2 Menu bar
3 Active area
Ref. Description
1 Area of the screen used to display the fault indicator, battery indicator, time, Getinge logo
and customer logo.
2 Area of the screen used to access the menus: home screen, presets, functions and set-
tings.
3 Area of the screen used to control the device.
Tab.11: Touchscreen control panel information
