Getinge Maquet PowerLED II User Manual

4
Use
Controlling the light
54 / 116
Maquet PowerLED II
IFU 01811 EN 10
4.2.4 AIM
4.2.4.1 From the lighthead or wall-mounted control keypad
10
4
4
10
2
9
7
9
7
Fig.55: AIM mode using the control keypads
For the wall-mounted control keypad, first select the lighthead 2 to be adjusted.
Enabling/disabling AIM mode
1. Enable AIM by pressing the AIM mode 10 button.
Ø The AIM mode 10 and Illumination adjustment 4 buttons are backlit on the keypad and
AIM mode is enabled.
2. Disable AIM by pressing the AIM mode 10 button.
Ø The AIM Mode 10 button is no longer backlit on the keypad and AIM mode is disabled.
Adjusting the light intensity with AIM
1. When AIM mode is enabled, press Plus 7 to increase the light intensity level of the light-
head(s).
2. When AIM mode is enabled, press Minus 9 to decrease the light intensity level of the light-
head(s).
NOTE
Boost mode is not available when AIM mode is enabled. In this case, the light has
10 illumination levels.
