Getinge Maquet PowerLED II User Manual

Use
Using the camera
4
Maquet PowerLED II
IFU 01811 EN 10
77 / 116
4.6.1.3 Control the 4K camera from the touchscreen control panel
NOTE
When using the touchscreen control panel, the camera may be turned on or off in-
dependently of the light.
2
1
Fig.93: Turn on the camera
Turning a camera on via the home page
1. Press the Camera active area 1 button.
Ø The activated button is lit green and the image is displayed on the screen.
2. Press the active Camera button 1 again to access the camera page.
Turning the camera on via the lighthead page
1. From the lighthead page, press the Camera shortcut 2 .
Ø The camera page is displayed and the camera is turned on.
3
4
Fig.94: Camera page
Turning off the camera
1. From the camera page, press Camera ON/OFF 3 to turn off the camera.
Ø The button light turns off and the camera is turned off.
Pausing the camera
1. Press the Camera pause 4 button to pause the camera.
Ø The button is lit blue and the retransmitted image is frozen.
2. Press the Camera pause 4 button again to resume video transmission.
