Getinge Maquet PowerLED II User Manual

Use
Positioning the light
4
Maquet PowerLED II
IFU 01811 EN 10
69 / 116
4.4.2.2 From the touchscreen control panel
1
2
3
Fig.78: Enabling the laser positioning assistance function via the touchscreen control panel
1. From the lighthead page, press the Laser 1 button.
Ø A pop-up window is displayed.
2. Press Enable Laser 3 to engage the positioning assistance function or Cancel Laser 2 to
return to the lighthead page.
Ø The light output level is reduced and two laser dots appear for 20seconds.
3. Position the lighthead so as to bring the two dots closer together.
Ø The lighthead is then at the optimum distance from the area to be illuminated.

Getinge Maquet PowerLED II Specifications

General

Brand	Getinge
Model	Maquet PowerLED II
Category	Medical Equipment
Language	English
