Getinge Maquet PowerLED II User Manual

Use
Controlling the light
4
Maquet PowerLED II
IFU 01811 EN 10
49 / 116
4.2.1.2 From the touchscreen control panel
1
2
3
4
Fig.50: Turning the light on and off via the touchscreen control panel
Turning on the light
1. Press the Lighthead1 active area 1 .
Ø The operation indicator 2 is activated and lighthead1 turns on.
2. Press the Lighthead2 active area 3 and then the Lighthead3 active area if available.
Ø The entire light is now on.
Turning off the light
1. Press the Lighthead1 active area 1 .
Ø The lighthead control page is displayed.
2. Press Lighthead ON/OFF 4 .
Ø Lighthead1 and the lighthead1 operation indicator are turned off.
3. Proceed in the same way for all lightheads that are on.
Ø The entire light is now off.

Getinge Maquet PowerLED II Specifications

General

Brand	Getinge
Model	Maquet PowerLED II
Category	Medical Equipment
Language	English
