8003 Precision Scalar Analyzer
3-60 Manual 20791, Rev. C, June 2001
Current Swept Measurement Example:
SWP? 3;abs;avg 16;srq;items 200
Current Swept Measurement Related Commands:
OUTPUT
GRAPH
SWPF
SWPS
Swept Measurements To Be Stored:
The second trace form of the SWP command stores, displays, or clears TRACE data.
Stored Swept Measurement Syntax:
SWP hs Channel Specifier us Memory Trace Specifier ds
Stored Swept Measurement Syntax:
SWP hs Channel Specifier us Memory Trace Specifier ds
Stored Swept Measurement Specifiers:
Trace specifiers: TRACE n, -TRACE n, STORE_TRC n, CLEAR_TRC n
valid n values: 0 through 9 (ALL is valid for CLEAR_TRC)
TRACE n: Programs the specified channel to display memorized
Trace n.
-TRACE n: Programs the specified channel to be ratio’ed with Trace
n.
STORE_TRC n: Stores a swept measurement to memorized Trace n.
CLEAR_TRC n: Clears a single measurement of all memorized traces.
Stored Swept Measurement Examples:
SWP 1;TRACE 4:
(makes channel 1 display memorized trace 4)
SWP 3;-TRACE 7:
(makes channel 3’s measurement a ratio of sensor A to trace 7)
SWP 4;STORE_TRC 8:
(stores the swept measurement being made by channel 4 into trace memory number 8)
SWP 2; CLEAR_TRC ALL:
(clears all stored traces)
Stored Swept Measurement Related Commands
INPUT
OUTPUT
NOTE:
To deactivate ratioing with a trace, use the MEAS modifier. See
MEAS modifier description on page 3-55 and the Trace Memory Programming
example on page 3-61.
☛
☛
