Flow Cell Maintenance
Replace the Inlet and/or Outlet Tubing
When replacing the inlet or outlet tubing, ensure that its ID is appropriate for the flow cell. Refer to the table
below for part numbers for replacement tubing and fittings.
To replace the tubing:
1 Disconnect the tubing from the flow cell and, if necessary, from the system.
2 Connect the fittings on the replacement tubing to the flow cell. Finger tighten the fitting.
3 Connect the other end of the tubing, if necessary.
Part Number Description
49041001 FITTING,FINGERTIGHT,10-32,KEL-F(F-100N)
49041011 FERRULE, 1/16", RED (P-200R)
49041012 NUT, 1/16", BLACK (P-201)
49951059 TUBING,.010" X 5FT, PEEK
49953059 TUBING,.030" X 5FT, PEEK
F1410153 COUPLING, 1/4-28
