Gilson 157/159 UV-VIS Detectors User’s Guide B-15
Front Panel Control
B
GLP Menu
GLP Menu
The GLP menu is for information purposes only. The submenus provide
information about the use of the detector, deliver an overview of the
configuration and inform as to the condition of the device. The data can be
viewed by touching the corresponding buttons.
Navigation
1Touch GLP to display operating parameters.
2 Touch the gray highlighted values to display all available options.
3 Touch to scroll through the other options in the GLP menu.
4 Touch to go to a higher level, or hold for two seconds to go to the Main menu.
Standby
By touching the Standby button, the detector goes into the energy saving standby mode. The word STANDBY
is displayed on the touchscreen and the standby lamp goes on. The event inputs and communication interfaces
remain active.
The return from standby mode is made by touching the touchscreen. The standby lamp goes out, and the device
behaves as it would if turned on with the power switch. No calibration takes place, as the set wavelength has
been fixed
