Grace m908 - Illustration 104: 32 Channel Digilink Connections

m908 User Manual, Rev. G
currently routable in the m908. The m908 Digilink interface is for monitoring outputs only at this
time. Future m908 firmware will allow analog or digital inputs on the m908 to be routed to the
Digilink interface.
There are two ways to connect the m908 to the HDX card or HD Native interface. See the
illustrations below.
When connected directly to an HDX or Native port the m908 will appear as two HD I/O
interfaces and will allow monitoring 32 channels.
